Mechanical Properties
| Mechanical Property | Characteristic Value |
|---|---|
| Unit Weight | 44 kg/m² |
| Uni-axial Compressive Strength (unfilled) | 160 kN/m (4.77 MPa) |
| Uni-axial Compressive Strength (M20 filled) | 1360 kN/m (10.96 MPa) |
| Uni-axial Tensile Strength | 35 kN/m (1.04 MPa) |
| Shear Strength (unfilled) | 21.6 kN/m |
| Shear Strength (M20 filled) | 61 kN/m |
| Ductility | 5.75 |
| Elastic Modulus | 4000 – 7500 MPa |
| Coefficient of Thermal Expansion | 12 × 10⁻⁶ mm/mm/°C |
| Water Absorption | 1% in 1 hr, 3.85% in 24 hr |
| Fire Resistance | 4 hr rating, withstood 700–1000 °C (Australia test) |
