Air  Receiver Tank
Type :  Horizontal Model
Capacity :  500  Litres
Working  Pressure :  7 Kg/cm2
Maximum Tested Pressure :  10.5 Kg/cm2
Type of testing:  Hydrostatic Pressure  testing
Type of  Welding :  Electric  Arc  Welding
 Interior Finish:  2 Coats of Rust Proof Red oxide primer
 Exterior Finish :  2 Coats of Enamel Paints over red oxide coat.
 Starter:  Star Delta Starter, Make BCH/L&T/TC
Auto  Pressure  Control :  Provided (Make – Micro)
Switch (Auto Start / Stop  Switch)   :  Cut  off at – 7 Kg/cm2
                                                            :  Restart at – 5 Kg/cm2
“V” Belt:  “C” Groove x  2 Nos
Non  return  valve :  Made of  aluminium casing  and  forged  gunmetal
                                                                guide  and spindle.
Safety Valve :  3 Nos
                         Air  Delivery  Line  - 1 No
                         Intercooler - 1 No
                        Air  Receiver - 1 No
Intercooler :  Radiator  type ; made of High conductivity  copper
                     Pipes Top & Bottom Header, Inlet & Outlet pipes
                    made of M.S. Sheet
After Cooler Pipes :  Radiator  type ; Made of High conductivity
                                 Copper  pipes ; Top & Bottom Header, Inlet &                                   Outlet pipes made of MS Sheet.
Pressure  Gauge :  100mm  dia ( Range 0 – 400 PSI)
Air Delivery  Valve :  Provided
Water  Drain Valve :  Provided(manual  type)
Belt Guard :  Provided

Model / Make:  CEC  Smart  Make
Rating:  20HP / 15 KW
Type of Cooling :  Fan Cooling
Speed at full  Load : 1440 RPM
Insulation :  “B” Class  or  superior
Voltage :  415V ± 10% 3 Phase
Frequency :  50Hz
Current (Full Load):  30 Amps, Maximum
Efficiency :  86% with admissible tolerance as per IS 325
Duty Class :  S1, Continuous
Rotor (Dynamically Balanced):  Copper Rotor – Dynamically Balanced
Rotor Shaft:  Shaft – En8 Material
Test Report :  As per IS 325
Frame Size & Dimensions:  Confirm as per to IS 1231
Performance Values :  Conform as per to  IS 8789
