Fully – Automatic Baling Machine

Description

Fabtex Engineering Works' Fully Automatic Horizontal Baling Presses deliver exceptional performance, compacting paper, plastic, and OCC cartons into dense, high-quality bales. Our machines efficiently process recyclable materials, making them perfect for medium to large-scale recycling operations. With a processing capacity of 10 tons per day and a compression force ranging from 400kN to 1200kN, each bale allows for optimal storage and transportation.

We've helped over 100 satisfied clients achieve their recycling goals, with our bales packing efficiently into containers, achieving 20-24 tons per 40' HQ container. Our balers ensure reliable and efficient operation, maximizing productivity and reducing labor costs

Get Enquiry

Applications

Paper (ONP, OMG, kraft paper)
Cardboard
Carton Boxes
Pet bottles
Natural fibers
Shredded material
Municipal Solid Waste
Shredded Paper
Hay

Technical Details

Specification	FAB/ATB – 40	FAB/ATB – 60	FAB/ATB – 80	FAB/ATB – 100	FAB/ATB – 150
Bale Size	Adj.	Adj.	Adj.	Adj.	Adj.
Width (inch)	31.50	43.31	43.31	43.31	43.31
Height (inch)	28.35	31.50	31.50	43.31	43.31
Bale Weight (kg/lbs)	Up to 250 / 551	Up to 350 / 771	Up to 650 / 1433	Up to 1000 / 2204	Up to 1200 / 2645
Production (bales/hr)	Up to 4	Up to 6	Up to 10	Up to 10	Up to 14
Motor Power (HP)	20	30	50	30 * 2	50 * 2
Overall Size (inch)	216’ x 120’ x 144’	276’ x 132’ x 144’	324’ x 156’ x 156’	360’ x 168’ x 156’	384’ x 168’ x 168’

Hydraulics & Add – On Features:

3 level safety interlocks for motor and pump
Auto – Tie to improve productivity
Hydraulic Pumps with very low noise level
Indigenous compact design of Hydraulic Control block offers a reliable function
Leakage – free hydraulic pipe with O-ring
Oil Cooler by Air/Water arrangements
180° Safety System
Continuous Cycle arrangements with PLC

Special Features:

400 kn – 2500 kn main-press
Single cylinder system
Automatic door locking system
