Tire Baler Press
Description
This heavy-duty Tyre Baler Machine delivers powerful compression for car, truck, and industrial tyres, designed to reduce bulk volume efficiently and safely. Perfect for recycling units, warehouses, and tyre shops, it ensures easier handling, optimized storage, and streamlined transport. Built for durability and high performance, it meets stringent industrial standards while providing reliable, long-term operation.
Applications
- Car tire
- Truck tire
- Jeep tire
- Bus tire
- Tire scrap
- Damaged tire
Technical Details
| Type | FAB/TB/09 | FAB/TB/14 |
|---|---|---|
| Capacity (tons / lbs) | 90 tons / 198,416 lbs | 140 tons / 308,647 lbs |
| Working Pressure (bar) | 150 | 200 |
| Baling Box Size (L×W) (mm/inch) | 1400 mm × 700 mm / 55.12 × 27.56 inch | 1600 mm × 900 mm / 62.99 × 35.43 inch |
| Bale Size (L×W×H) (mm/inch) | 1400 mm × 700 mm × 900 mm / 55.12 × 27.56 × 35.43 inch | 1600 mm × 900 mm × 1000 mm / 62.99 × 35.43 × 39.37 inch |
| Motor Power (HP) | 20 | 30 |
| Oil Tank Capacity (Lit) | 400 | 600 |
| Number of Hoops | 5 | 7 |
| Production (Bale/hr) | 2–3 | 2–3 |
| Weight of Machine (tons / lbs) | 3.5 tons / 7,716.18 lbs | 5 tons / 11,023.1 lbs |
| Daylight (mm/inch) | 1900 mm / 74.80 inch | 2400 mm / 94.49 inch |
Add-On Features
- Sliding door increases work efficiency and saves labor.
- Door opening and closing is hydraulic-driven to ensure operational safety.
- Fixed retainer dogs hold the pressed material from springing back.
- High compaction ratio.
- Effective operation inspection window for safety and dust reduction.
- Oil cooler provided to maintain viscosity of oil.
- Automatic bale ejector with chain simplifies bale ejection.
Why Choose Our Vertical Hydraulic Tire Baling Press?
- Reliable Performance: Built to withstand heavy-duty use and deliver consistent results.
- Customizable: Can be tailored to meet specific application requirements.
- Excellent Support: Backed by our dedicated customer support team.
The Following Machine Can Bale:
- Used tyres / scrap tyres – car, truck, bicycle, jeep, or industrial tyres.
- Rubber waste – rubber offcuts or scrap from manufacturing.
Experience the Power of Our Vertical Hydraulic Tire Baling Press
- Discover how our Vertical Hydraulic Tire Baling Press Machine can benefit your business. Contact us to learn more about our tire baling solutions and how we can help you achieve your waste management goals.
