Double Shaft Shredder
Description
The Fabtex Dual Shaft Shredder is a heavy-duty, industrial-grade machine designed for high-volume size reduction and shredding applications. With its robust dual-shaft design, this shredder delivers exceptional performance, efficiency, and reliability.
Applications
- Plastics (bottles, containers, pallets)
- Wood (pallets, crates, furniture)
- Metal (scrap metal, aluminum cans)
- Paper (cardboard, boxes, documents)
- Municipal Solid Waste (MSW)
- E-Waste (computers, phones, electronics)
- Textiles (clothing, fabric scraps)
- Rubber (tires, hoses)
- Glass (bottles, jars)
- Biomass (agricultural waste, wood chips)
Technical Details
| Specification | FAB - 250 | FAB - 350 | FAB - 450 | FAB - 550 | FAB - 650 |
|---|---|---|---|---|---|
| Cutting Chamber (L × W) (inch) | 31.50 × 15.75 | 31.65 × 26.77 | 39.37 × 26.77 | 47.24 × 36.22 | 59.21 × 53.54 |
| Motor Power (hp) | 15 × 2 | 20 × 2 | 30 × 2 | 50 × 2 | 50 × 2 |
| Cutter Diameter (inch) | 7.87 | 17.72 | 17.72 | 22.05 | 29.53 |
| Cutter Thickness (inch) | 24 | 30 | 30 | 40 | 50 |
| Overall Size (L × W × H) (inch) | 120 × 72 × 96 | 132 × 96 × 96 | 144 × 96 × 144 | 192 × 96 × 144 | 216 × 96 × 144 |
Core Performance
- Low Speed / High Torque Design
- Easy Accessibility
- Jam-Proof Design
- Low Noise
- Large Infeed Hopper
- Rugged Hydraulics
- 4-Way, Indexable Cutting Inserts
- High Output “Torsion Point” Cutting Rotor
- Severe Duty Construction
- Automatic Overload Cut-off System
- Input and Output Conveyor as Optional
- PLC Control Panel
- ISO 9001 Manufactured
Special Features
- 100 – 10000 kgs Production
- Hydraulic Cylinder Pusher System
- Door Interlocking System
Benefits
- Increased Efficiency: High-volume shredding capabilities reduce processing time
- Improved Safety: Designed with safety features to protect operators and prevent accidents
- Reduced Maintenance: Durable construction and easy-to-replace parts minimize downtime
Experience the Power of Fabtex Dual Shaft Shredders
- Upgrade your shredding capabilities with the Fabtex Dual Shaft Shredder. Contact us to learn more about how our machines can benefit your business.
